Seat widths without protection panels

480, 490, 500, 510, 520, 530, 540, 550mm

Seat widths with protection panels

480, 500, 520mm

Height when open

920mm

Height when closed

835mm

Depth when open

655mm

Depth when closed

165mm

Minimum row depth on TX platforms

850mm

Minimum row rise on TX platforms

280mm (Add 20mm for plastic panels)Enquire Now

The Espace 628CC is the most luxurious member of the Espace 628 family, with a supportive high backrest and a thick, sprung seat specially designed for the comfort of conference delegates or concert goers.

Ergonomically designed

The thick, sprung seat is designed to support conference or concert attendees throughout lengthy events.

Compact closed profile

Just 165mm deep (170mm with plastic protection panel to the rear), creating generous walkways in front of the chairs.

Seamless mechanism

The seat and back fold up and the armrest automatically tips to form a neat closed envelope.

Nylon bushings for silent operation

Ideal for performing arts spaces.

Versatile

Suitable for both retractable platforms, traditional fixed auditoria and on our removable matrix system.

Tested for Safe Emissions

A representative sample has been tested for emissions of three key chemicals: VOCs, formaldehyde and acetaldehyde. The emissions fell within acceptable limits specified within the BREEAM, LEED and WELL standards. We can supply details to building designers on request.

Plastic Panels

Durable plastic opanels are available for the outer side of the back.

The plastic panels wrap right around the corners of the upholstery, significantly reducing upholstery wear.

All versions of the chair feature a protective steel kickplate to the lower third.

Fixed Back Option

Normally, the backrest moves down as the seat tips up to form a neat closed envelope. In some venues, a static backrest may be more appropriate.

Armrests

Choice of ABS, standard timber or contoured timber.

Seat Identification

Seat numbers and aisle letters.
