Features & Benefits
-
Effortless
Operate at the touch of a button
-
Electrically Controlled
Via a control console or a computer
-
Programmable
Using the console, preset heights can be created. Using the computer, large configurations using multiple stages can be saved an instantly activated.
-
No separate storage space required
Stage just stows away in the floor
-
Continuously Adjustable
Set at any height up to 1330mm
-
Our Most Heavy-Duty Stage
Constructed from steel
Options
Accessories
- Stairs
- Step lighting
- Access ramps
- Banisters
- Safety rails
- Trolleys for accesories
- Stage skirting or fascias
- Service access hatches
Step unit
Left to right: Drapes, wheelchair access ramp, service access hatch
Rail Options
Surface Plate Finishes
Weather resistant black; weather resistant dark brown
Varnished natural beech; varnished natural plywood
Oak parquet
Dimensions & Specifications
Pit Height
Max 200mm
Height Adjustability
Continuous up to 1330mm above floor level
Surface Dimensions
2m x 1m. Custom dimensions available on request.
Lift speed
8mm/s
Motor
0.37kW
Electrical supply
400V
Control Voltage
24V
Accreditation and Certification
DIN 56950, BGV CI
