Features and Benefits

  • Certification and Accreditation

    TÜV/GS, verified static calculations, DIN4112/1055/15920

  • Small Storage Footprint

    The scissoring folding legs make this model space-efficient to store.

  • Multiple Uses

    Suitable to create stages, stepped structures, rostra or choir stages.

  • HIgh Performance Load Bearing

    Up to 750kg/sqm

  • Flexible and Easy to Assemble

    Modular system with a sturdy clamping system to join stages together.

  • Lightweight

    Low overall weight, with aluminium profiles.

  • Customisable

    A wide range of surface finishes is available, but further customisations can be made on request. Please discuss your requirements with us.

Options

 Accessories

  • Component connection clamps
  • Stairs
  • Access ramps
  • Banisters
  • Safety rails
  • Horizontal stacking trolley
  • Vertical stacking trolley
  • Stage skirting in a choice of fullness
  • Angle brackets
  • Service access hatches

Step unit



Left to right: Drapes, wheelchair access ramp, service access hatch



Above: Adjustment mechanism release hanles; overall understructure

Rail Options







Surface Plate Finishes



Chequerboard; weather resistant black



Weather resistant dark brown; varnished brown



Varnished natural beech; varnished natural plywood

Dimensions

Surface Plate Dimensions

2m x 1m, 1m x 1m or 2m x 0.5m as standard. Custom dimensions available on request.

Height Adjustment

Scissors 80: 100mm, 400mm, 600mm, 800mm Scissors 100: 170mm, 400mm, 600mm, 800mm, 1m

Profile / Stacking Height

Scissors 80: Profile height 90mm, stacking height 100mm Scissors 100: Profile height 90mm, stacking height 170mm

Weight

Scissors 80: Approx 44kg. Scissors 100: Approx 50kg.

Trenomat Scissor Datasheet
Download
